Description
Product Details: IEC C14, 3 Pin Snap Fit to Panel Electrical Power Inlet
Fits Vacuum: Rugged Advantage Model 15721000, and Rugged D’Lite Model 15721100
Brand: Rong Feng SS 120
Standard: IEC 60320
Panel Thickness: 2.0mm
Connection: 6.3mm Tab
Electrical Rating: 10A 250V a.c.
Temperature Limit: 70°C
Panel Cut Out: 20.5mm x 27.5mm
Overall Dims: 23.5mm height x 30.5mm wide x 35.4mm deep
